GE IC695ACC652

The workshop environment is so poor that the machines keep breaking down. What should we do? This GE IC695ACC652 anti-magnetic anti-interference device is extremely effective. It is well-made. The warehouse has sufficient in-stock items, and the delivery is very fast. Just contact Quanzhou Xin Yuan Technology directly.

Technical Specifications

Contact Configuration A multi-layer high-density pin array design is adopted. The connector contacts of the backplane bus are gold-plated to ensure low impedance and high conductivity for signal transmission between the CPU module and each I/O module, effectively reducing high-frequency signal attenuation.

Rated Voltage The backplane supports a maximum working voltage of 5 VDC and 24 VDC dual-bus power supply architecture. The wide voltage tolerance design can withstand the impact caused by grid fluctuations.Rated Current The continuous rated carrying current of the backplane bus can reach up to 10 Amps, providing abundant power transmission for the I/O module group in full-load conditions, and preventing the end modules from running out of power and causing a system failure.

Electrical Life Under industrial-grade full-load insertion and long-term power-on operation tests, the electrical life of the backplane pins and internal PCB traces can reach more than 100,000 insertion and removal cycles, with extremely low physical and electrical aging rates.

Installation Method A standardized backplane rail-mounted installation design is adopted. The back of the baseplate is equipped with a fixing latch, which supports direct and quick locking onto standard DIN rails or control cabinet installation plates. The module insertion adopts a foolproof design and lever-assisted mechanism to ensure correct blind insertion.

Quality control standards

The back panel of GE IC695ACC652 uses high TG flame-retardant copper-clad laminate to resist deformation and alloy pins to prevent metal fatigue. The entire line adopts automatic wave soldering and AOI optical inspection to eliminate false soldering and missed soldering. Before leaving the factory, it undergoes full-point flying probe testing. The internal equal-length wiring design strictly controls impedance and completely suppresses signal crosstalk.

Operating environment

The GE IC695ACC652 is capable of operating within a wide temperature range of 0°C to 60°C and can be stored at -40°C. It is not affected by extreme cold or heat. The reinforced mechanical structure effectively buffers the high-frequency vibrations in industrial environments, ensuring that the module does not loosen. The built-in shielding layer design protects against electromagnetic interference and surge pulses from frequency converters and high-power motors.

Market Legend

When it comes to the model GE IC695ACC652, those familiar with industrial control know that its communication is extremely reliable, with almost no packet loss. With so many second-hand refurbished boards available on the market, Quanzhou Xin Yuan Technology dares to promise with confidence that we will only produce genuine new products, and this has spread throughout the industry.

FAQ module

Q1 Is this baseboard compatible with the older series modules from the past?

A1 This baseboard is specifically designed for the RX3i high-performance system. Although it supports the migration of some older models at the software level, it is not recommended to mix it with non-specific older baseboards due to the potential mismatch in communication timing.

Q2 How is the current inventory situation in the market? Can the original brand be guaranteed?

A2 Quanzhou Xin Yuan Technology has a ready supply of brand new original equipment. All batches have been verified and tested by the original factory for their sealed packaging and strict quality control, ensuring that the circuit board pins are not oxidized and that the inspection reports are complete.
