For industrial automation projects that depend on stable fieldbus communication, Xin Yuan provides sourcing support for Siemens 6XV1830-0EH10, a shielded PROFIBUS FC Standard Cable GP designed for fast installation and dependable signal transmission. Its two-wire construction, 150 Ω nominal impedance, FastConnect-compatible design, and industrial temperature range make it a practical solution for PROFIBUS networking in automation and control environments.
The Siemens 6XV1830-0EH10 is a 2-core shielded PROFIBUS bus cable developed for industrial communication applications. Siemens identifies it as a PROFIBUS FC Standard Cable GP with a special construction for quick assembly. The cable is supplied by the meter, with a maximum delivery unit of 1000 m and a minimum order quantity of 20 m. Its 150 Ω nominal impedance, shielded structure, FastConnect capability, and -40°C to +75°C operating range make it suitable for demanding industrial networking installations.
Table of Contents
- What Is Siemens 6XV1830-0EH10?
- What Are the Key Specifications?
- How Does Its Cable Construction Support Reliable Communication?
- What Are the Main Advantages?
- Where Can Siemens 6XV1830-0EH10 Be Used?
- What Should You Consider During Installation?
- How Should Buyers Select the Right Cable?
- Frequently Asked Questions
- Conclusion
What Is Siemens 6XV1830-0EH10?
Siemens 6XV1830-0EH10 is a PROFIBUS FC Standard Cable GP belonging to the Siemens connecting-cable product family. Siemens describes it as a two-wire, shielded bus cable with a special construction intended for quick installation. The official Siemens product listing identifies the product as an active product and specifies a maximum delivery unit of 1000 meters, with a minimum order quantity of 20 meters when sold by the meter.
Designed for PROFIBUS communication systems, the cable is particularly relevant to industrial automation environments where programmable controllers, distributed I/O, drives, sensors, and other field devices need dependable data communication.
Its FastConnect-compatible construction is one of the important characteristics for installers because it can simplify cable preparation and termination when compatible installation practices and connectors are used.
What Are the Key Specifications?
Understanding the technical parameters is essential when selecting a PROFIBUS cable. The following specifications summarize important characteristics associated with Siemens 6XV1830-0EH10.
| Parameter | Specification |
|---|---|
| Product | Siemens 6XV1830-0EH10 |
| Cable type | PROFIBUS FC Standard Cable GP |
| Electrical cores | 2 |
| Nominal impedance | 150 Ω |
| Capacitance at 1 kHz | 28.5 pF/m |
| Maximum loop resistance | 110 mΩ/m |
| Maximum shield resistance | 9.5 Ω/km |
| Outer cable diameter | Approximately 8 mm |
| FastConnect | Yes |
| Operating temperature | -40°C to +75°C |
| Minimum single-bend radius | 37.5 mm |
| Minimum multiple-bend radius | 75 mm |
| Maximum tensile load | 100 N |
| Cable sheath | PVC, violet |
| Approvals/conformity | CE, UL, RoHS |
The technical data shows why this cable is positioned as an industrial PROFIBUS communication solution rather than a general-purpose signal cable. Its impedance and electrical characteristics are designed around PROFIBUS network requirements, while the shielding and mechanical construction help support reliable field installation.
How Does Its Cable Construction Support Reliable Communication?
A fieldbus cable must maintain signal integrity while operating alongside motors, drives, switching equipment, and other potential sources of electromagnetic interference. Siemens 6XV1830-0EH10 uses a shielded two-core construction to address these requirements.
The shielding consists of an aluminum-clad foil combined with a braided screen made from tin-plated copper wires. This multilayer shielding structure provides an additional barrier against electromagnetic interference that could otherwise affect communication quality.
The cable uses polyethylene for the conductor insulation and PVC for the inner and outer sheath. The conductors are identified in red and green, while the external sheath is violet, making the cable relatively easy to distinguish during installation and maintenance.
The cable also supports FastConnect installation. This feature is valuable in projects where installation speed and consistent termination are important considerations.
What Are the Main Advantages?
Several characteristics make Siemens 6XV1830-0EH10 attractive for industrial PROFIBUS installations.
- Stable electrical performance: A nominal impedance of 150 Ω is suitable for PROFIBUS communication applications.
- Effective shielding: The foil and braided copper shielding helps protect communication signals from electromagnetic interference.
- Fast installation: FastConnect compatibility supports efficient cable preparation and termination.
- Wide temperature range: The specified operating range of -40°C to +75°C supports a broad range of industrial environments.
- Recognizable industrial construction: The violet PVC sheath makes PROFIBUS cabling easier to identify in complex control systems.
- Flexible procurement: Siemens specifies the product as meter goods, allowing cable quantities to be matched to project requirements.
These characteristics can be especially valuable when network reliability, installation efficiency, and maintainability are more important than simply minimizing initial cable cost.
Where Can Siemens 6XV1830-0EH10 Be Used?
Siemens 6XV1830-0EH10 is intended for PROFIBUS networking and can be considered for a variety of industrial automation scenarios. Typical applications include:
- PLC and distributed I/O communication
- Industrial machine automation systems
- Factory production lines
- Process automation installations
- Control cabinets and industrial cable routes
- Drive and automation communication networks
- Retrofit and maintenance projects involving PROFIBUS infrastructure
For example, an automated production line may use PROFIBUS to connect a central controller with distributed field devices. In such a system, selecting a properly specified bus cable is important because poor shielding, unsuitable impedance, or incorrect installation can contribute to communication errors and network instability.
What Should You Consider During Installation?
Even a high-quality industrial communication cable can experience problems if it is installed incorrectly. When working with Siemens 6XV1830-0EH10, installers should pay attention to mechanical routing, bending, shielding, and termination.
1. Respect the bending radius
The specified minimum bending radius is approximately 37.5 mm for a single bend and 75 mm for multiple bends. Avoid forcing the cable into tight corners because excessive mechanical stress can damage the cable structure or negatively affect long-term reliability.
2. Avoid unnecessary electromagnetic interference
Where possible, communication cables should be routed appropriately in relation to high-power cables, motors, frequency converters, and other strong interference sources. Proper separation and grounding practices should follow the relevant PROFIBUS installation guidelines.
3. Use suitable termination components
FastConnect capability can simplify termination, but the cable should still be paired with compatible connectors and installation components. Poor termination can create communication problems even when the cable itself meets the required specifications.
4. Protect the cable from excessive mechanical stress
The stated maximum tensile load is 100 N. Cable pulling and routing procedures should therefore avoid excessive tension during installation.
How Should Buyers Select the Right Cable?
When purchasing Siemens 6XV1830-0EH10 for an automation project, technical compatibility should be considered alongside procurement requirements.
- Confirm the exact part number: Verify that the required product is 6XV1830-0EH10 rather than another Siemens PROFIBUS cable variant.
- Check network requirements: Confirm that the cable specifications match the intended PROFIBUS application.
- Estimate cable quantity: Siemens lists a maximum delivery unit of 1000 m and a minimum order quantity of 20 m for the product sold by the meter.
- Evaluate installation conditions: Consider temperature, bending requirements, routing conditions, and electromagnetic environment.
- Verify connector compatibility: Make sure the selected termination solution is appropriate for the cable and network architecture.
- Choose a reliable supplier: For industrial automation components, traceability, product authenticity, packaging, and technical support can be as important as price.
For international buyers looking for a China supplier or industrial automation sourcing partner, Xin Yuan can help customers evaluate product specifications and procurement requirements before ordering.
Frequently Asked Questions
What is Siemens 6XV1830-0EH10 used for?
Siemens 6XV1830-0EH10 is a shielded two-wire PROFIBUS FC Standard Cable GP designed for industrial PROFIBUS communication networks. It can be used for connecting automation devices and field components that communicate through PROFIBUS.
What is the impedance of Siemens 6XV1830-0EH10?
The nominal impedance is 150 Ω. This is an important electrical characteristic for maintaining suitable signal transmission in PROFIBUS networks.
Does Siemens 6XV1830-0EH10 support FastConnect?
Yes. The product specifications indicate that Siemens 6XV1830-0EH10 supports FastConnect, making it suitable for installation methods designed around compatible FastConnect components.
What is the operating temperature range?
The specified operating temperature range is -40°C to +75°C. The same temperature range is also specified for storage, transportation, and installation.
What is the outer diameter of the cable?
The specified outer cable diameter is approximately 8 mm, with a symmetrical tolerance of 0.4 mm.
Is Siemens 6XV1830-0EH10 shielded?
Yes. The cable uses an aluminum-clad foil together with a braided screen made from tin-plated copper wires, providing shielding for industrial communication applications.
What is the minimum bending radius?
The minimum permissible bending radius is approximately 37.5 mm for a single bend and 75 mm for multiple bends. Installation should follow the applicable technical documentation and project requirements.
How is Siemens 6XV1830-0EH10 supplied?
Siemens lists it as meter goods, with a maximum delivery unit of 1000 m and a minimum order quantity of 20 m. Buyers should confirm current commercial terms and availability before placing an order.
Conclusion: Is Siemens 6XV1830-0EH10 a Good Choice for PROFIBUS Networks?
Siemens 6XV1830-0EH10 combines a 150 Ω nominal impedance, two-core shielded construction, FastConnect compatibility, an approximately 8 mm outer diameter, and a -40°C to +75°C operating range in a cable specifically designed for PROFIBUS applications. These characteristics make it a practical option for industrial automation networks where communication stability, installation efficiency, and long-term serviceability are important.
For engineers, system integrators, maintenance teams, and procurement professionals, choosing the correct cable should involve more than comparing unit prices. Network compatibility, installation conditions, shielding requirements, cable length, connector selection, and supplier reliability should all be evaluated together. If you are looking for a reliable sourcing solution for Siemens 6XV1830-0EH10 or need assistance confirming specifications and procurement requirements, contact us today for professional product support and a suitable quotation.
Note: Product specifications and commercial availability can change. Buyers should verify the latest manufacturer documentation and project-specific requirements before final procurement.
